• Fully multiplex electrical system
  • Equipped with ADA (Americans with Disabilities Act) wiring, which offers body builder interface connections, eliminating the need for OEM’s to splice into chassis wiring

S2C Bumper


  • Single- or Three-piece steel or chrome
  • Optional plastic ends molded for integral fog lights on three-piece

S2C Tires






With an array of options, Michelin tires are made to suit the needs of any commercial bus on the road today.

Michelin® 245/75R 22.5″ 14-ply through 11R 22.5″, most treads
Michelin 255/70R 22.5″ 16-ply

For specific tire information, take a look at Michelin Tires.




Handling Luxury with Precision.

As the first line of tag axles that are fully-integrated and precision-tuned to react to turns and maneuvers of the coach, UltraSteer establishes a new standard for premium RV ride and handling.


  • Auto-Locks to straight @ 20mph and in reverse for complete control
  • Flexible coach packaging for increased storage options
  • QuickAlign and optimized rubber bushings increase suspension life and reduce maintenance
  • Compatible with disc and drum brakes

Increased Maneuverability

  • Up to 17% reduction in curb-to-curb turning radius as compared to an ordinary fixed tag axle—140% improvement over the competition
  • 20% tighter turning angle than the nearest competitor

Improved Ride & Handling

  • UltraSteer’s outboard-mounted design is more reactive to roll input than inboard-mounted shocks, which improves handling in turns and maneuvers such as sudden lane changes
  • Wide track suspension arms provide increased lateral stiffness over narrow track suspension arms, improving handling and safety (B-Series)

Tire Savings

  • In contrast to rear mounted tie rods that can still cause tire scrub, the UltraSteer’s forward-mounted tie rods and correct steering geometry enable the inside wheel to have a 12° turning angle and follow the ideal turning path—eliminating tire scrub


  • B-Series

    A straight beam axle and wide track suspension arms provide increased lateral stiffness, delivering improved handling and safety in turns and sudden maneuvers while offering OEMs flexible floorplan options.

  • I-Series

    An independent suspension on the tag axle provides enhanced overall ride quality and stability, with a comparable weight capacity and turning angle to the B-Series.

B-Series I-Series
Ride Quality Good Best
Roll Stability Good Best
Side to Side Stability Good Best
Weight Capacity (GVWR) Best Best
Turning Angle Best Best
Coach Packaging Best Good

Neway Tag Axle

Neway Tag Axle

  • Additional payload capacity – up to 47,000 lb. GVWR
  • Longer floor plans – the tag axle accommodates floor plans up to 45 feet for more space and design options
  • Integrated into the overall chassis, enhancing overall stability and provides consistent braking – not just an “add-on” to handle more weight
  • Automatic load proportioning system – an industry first – distributes weight proportionately across all three axles to ensure a smoother, more comfortable ride and decrease tire scrub during low speed and back up
  • CAD-designed coupling plate provides superior strength in high-stress areas
  • Five-year, 100,000-mile coolant is pre-charged with SCA
  • Air-disc brakes with ABS dramatically decrease stopping distance in virtually all braking conditions, while minimizing fade during rapid or extensive application of the brakes

Tuned Taper-Leaf Spring Rear Suspension

Tuned Taper-Leaf Spring Rear Suspension

15,000 – 17,500 lbs.

Minimize the effects of potholes and bumps on uneven road surfaces. Durable and dependable, FCCC’s tuned taper-leaf spring rear suspension allows for reduced downtime and repair, with increased GAWR for greater payload capacity.

Parts and Service – 24/7 Direct

The only 24/7 support directly from the manufacturer.
